Working principle

Under the control of computer, the machine uses data line to control multi-channel lasers, make the color separated pattern information dot matrix recover. Then engrave the coated and dry screen. The exposed part of the sensitive emulsion is instantaneously vaporized. The dust removal system is used to remove the gasification dust. So the required patterns are engraved.



Technical parameters

Product model	XC2200A	XC3200A
Equipment size	4300×1280×1500(mm)	5300×1280×1500(mm)
Effective pattern size	2200(mm)	3200(mm)
Rotary screen size	640、  819、  914、  1018、 (Cpational)
Laser	1 /2  (Cpational)
Engraving speed	（2000mm,640mm, --------5--40min）
Engraving precision	254、508、1016  /  300、600   /  360、720、（dpi）
Power supply	AC380V      50-60HZ        8    /    12KW
Temperature	Temperature25-30℃,
Computer operation system	3Win7/win10

Product advantage

1, Energy saving and environmental protection, no water development and washing.

2, Short engraving process and less artificial operation

3. No need of darkroom. It can be operated all day.

4. High engraving precision

5. Net screen can be prepared in advance, no time limit.

6. Simple operation.
